MRI Compatible babyPac Ventilator with Integrated Alarms

Our Products: MRI Equipment > MRI Respiratory > MRI Compatible Ventilator - Equipment
SKU: 311-783
MRI Compatible babyPac Ventilator with Integrated Alarms
You can earn 13074 Ocelco Cash Reward Points on this product!
Price: $13,073.68
MRI Compatible babyPac Ventilator with Integrated Alarms
MRI Compatible babyPac Ventilator with Integrated Alarms
Previous Item Previous Item   Next Item Next Item
Product Details

MRI Compatible Baby Pac Ventilator with Integrated Alarms

Specially designed to deliver ventilation to small, fragile lungs of patients ranging from neonates through pediatrics up to 20kg with precision and confidence. It has a sophisticated range of ventilation controls including CPAP, variable I:E ratio and variable oxygen concentration. The latter is particularly important in neonatal intensive care and transport since high oxygen concentrations over a prolonged period can be harmful. Baby Vent also incorporates a comprehensive range of alarms.

Product Features
1 Year Warranty
Unique variable oxygen concentration gas mixing system
Inspiratory pressure control
Separate controls for inspiratory and expiratory time
Four operating modes
PEEP/CPAP control
Adjustable pneumatic pressure relief with audible alarm
Integrated pressure monitoring/alarm system
MRI compatible up to 3 Tesla
Low gas supply indicators for O2 and air
Complete pneumatic operation
Lightweight and durable

Specifications / Technical Data
Principle of Operation Time/pressure cycled
User Type Neonates and Infants up to 44 lbs. (20 kg)
Ventilation Mode
CMV + PEEP
CMV + Active PEEP
IMV + CPAP
CPAP
Tidal Volume 330 - 0 ml
Inspiratory Time 0.25 - 2.0 seconds
Expiratory Time
0.25 - 4.0 seconds
IMV 2.5 - 40 seconds
Frequency & I:E Ratio
10 - 80 b/min (I:E 1:2)
12 - 96 b/min (I:E 1:1.5)
15 - 120 b/min (I:E 1:1)
Flow Within Breathing Circuit Preset at 10 L/min
Air Mix
45 - 100% O2 oxygen only as supply
21 - 70% O2 oxygen and air as supply
Pressure Relief with Pneumatic Audible Alarm 10 - 80 cm H2O (10 - 80 x 100Pa)
Electronic Pressure Monitoring/Alarm System Optional " Visual and Audible Alarms for: High Pressure; Continuous Pressure; Low/Disconnect Pressure, Low Air Supply Pressure; and Low Battery
Inflation Pressure Monitor
-10 to + 100 cm H2O
-10 to + 100 (x 100) Pa
PEEP Capability 0 - 20 cm H2O (0 - 20 x 100P) with click action warning above 10 cm H2O
Active PEEP 2/3 - 20 cm H2O (2/3 - 20 x 100Pa) with click action warning above 10 cm H2O
MRI Compatible 3 Tesla actively shielded magnet with a max gradient of 430 G/cm and RF of 0.82 W/kg at 125.5 Mhz
Dimensions
3.7" H x 8.7" W x 6.4" D
9.2 cm H x 22 cm W x 16.2 cm D
Weight 8.3 lbs (3.75 kg)
Standards EN60601-1, EN794-3: 1999
